Technical specs
Full parametrics
Output & Regulation
10 params- Output Type
- Adjustable
- Number of Regulators
- 1
- Output Configuration
- Positive
- Voltage - Output (Min/Fixed)
- 0V
- Voltage - Output (Max)
- 14V
- Voltage - Input (Max)
- 14V
- Current - Output
- 3A
- Current - Quiescent (Iq)
- 50.5 µA
- PSRR
- 85dB ~ 20dB (120Hz ~ 1MHz)
- Protection Features
- Over Current, Over Temperature, Short Circuit
Electrical & Package
2 params- Current - Supply (Max)
- 1 mA
- Operating Temperature
- -55°C ~ 125°C
Compliance & Lifecycle
1 param- Lifecycle Status
- Obsolete
Additional Specifications
1 param- Voltage Dropout (Max)
- 0.42V @ 3A
