Technical specs
Full parametrics
Output & Regulation
10 params- Output Type
- Adjustable
- Number of Regulators
- 1
- Output Configuration
- Negative
- Voltage - Output (Min/Fixed)
- 0V
- Voltage - Output (Max)
- -32V
- Voltage - Input (Max)
- -36V
- Current - Output
- 600mA
- Current - Quiescent (Iq)
- 1.4 mA
- PSRR
- 85dB ~ 20dB (120Hz ~ 1MHz)
- Protection Features
- Over Current, Over Temperature, Reverse Polarity, Short Circuit
Electrical & Package
2 params- Current - Supply (Max)
- 22.5 mA
- Operating Temperature
- -55°C ~ 150°C (TJ)
Compliance & Lifecycle
1 param- Lifecycle Status
- Obsolete
Additional Specifications
2 params- Control Features
- Enable
- Voltage Dropout (Max)
- 0.45V @ 600mA
