Technical specs
Full parametrics
Output & Regulation
9 params- Output Type
- Fixed
- Number of Regulators
- 1
- Output Configuration
- Positive
- Voltage - Output (Min/Fixed)
- 1.5V
- Voltage - Input (Max)
- 5.5V
- Current - Output
- 250mA
- Current - Quiescent (Iq)
- 550 µA
- PSRR
- 58dB ~ 37dB (100Hz ~ 10kHz)
- Protection Features
- Over Current, Over Temperature, Short Circuit, Reverse Polarity
Electrical & Package
2 params- Current - Supply (Max)
- 950 µA
- Operating Temperature
- -40°C ~ 125°C
Compliance & Lifecycle
1 param- Lifecycle Status
- Obsolete
Additional Specifications
2 params- Control Features
- Enable
- Voltage Dropout (Max)
- 0.15V @ 250mA
